1) Usage:



1.This machine is suitable for side heat sealing and cutting,It is a kind of ideal machine to make BOPP ,OPP,PP,PE material's socks bag,towel bag,bread bag,ornament bag etc pakcing bag.

2.This machine is equipped with computer to set the bag length and batch etc.to make the bag automaticlly,also the machine is with adhesive tape device,lace heat sealing knife,hole puncher,photocell, automatic material feeding device,automatic constant temperature control device, electrostatic removing device,automatic counting and alarm device etc.It's easy operation, stable performance and with high producing speed.



2) Specification:



Model No.		RFQ-500	RFQ-600
Width of Bag Making		30-450mm	60-550mm
Length of Bag Making		45-600mm	50-700mm
Speed of Bag Making		30-240pcs/min	30-240pcs/min
Accuracy		±0.3mm	±0.3mm
Power		3.5kw	4kw
Weight		700kg	800kg
Machine Dimension(mm)		3500x1000x1300	3500x1100x1300



Model No.	RFQ-700	RFQ-800	RFQ-900	RFQ-1000
Width of Bag Making	70-650mm	80-750mm	90-850mm	90-950mm
Lenght of Bag Making	50-800mm	55-999mm	60-999mm	60-999mm
Speed of Bag Making	30-240pcs/min	30-240pcs/min	30-240pcs/min	30-200pcs/min
Accuracy	±0.3mm	±0.3mm	±0.3mm	±0.3mm
Power	4.5kw	5kw	6kw	6kw
Weight	900kg	1000kg	1100kg	1200kg
